| 1. Height (center) |
1170mm |
Headrest/Seat Arms/Safety Belt/Mechanical lumbar adjustment device |
| 2.Cushion Width |
510mm |
| 3. Backrest Width |
480mm |
| 4. Surface Height |
420mm |
| 5. SIP Point |
To the Front 330mm To the Bottom 450mm |
| 6. Headrest Adjustment Range (Angle、Height) |
80°、75mm |
| 7. Backrest Adjustable Angle |
Front 60°、Back 80° |
| 8. Front to Back Adjustable Distance |
175mm |
| 9. Height adjustment Distance |
60mm |
| 10. Skin Material |
PVC synthetic leather or fabric |
| 11. Installing Hole Size |
216*310*4-φ11 |
| 12. Arms are adjustable (luxury) |
|
| 13.. Surface Angle Range |
±12° |
| 14. Shock Damping Mode |
Mechanical Damping |
| 15. Seat lumbar |
totally 3 gears mechanical adjustment front and back |
| 16. Damping Device Stroke |
80mm |
| 17. Weight Adjustable Range |
50kg-130kg |
