| 1. Height (center, headrest in lowest position) |
900mm |
Headrest/Seat Arms/Safety Belt |
| 2.Cushion Width |
480mm |
| 3. Backrest Width |
460mm |
| 4. Surface Height(center) |
400mm |
| 5. SIP Point(center) |
To the Front 290mm To the Bottom 440mm |
| 6. Skin Material |
PVC synthetic leather or fabric |
| 7. Installing Hole Size |
260*315*4-φ11 |
| 8. Height adjustment range |
60mm |
| 9. Backrest Adjustment Angle |
Front 60°、Back 80° |
| 10. Shock Damping Mode |
Mechanical Damping |
| 11. Damping Device Stroke |
80mm |
| 12. Weight Adjustable Range |
50kg-130kg |
| 13. Front to Back Adjustable Distance |
175mm |
